Proximity sensors are categorized into electromagnetic field sensors and capacitive effect sensors, which detect the presence or approach of an object without physical contact. They replace traditional contact-based detection methods such as limit switches. The principle involves converting the movement or presence of a detected object into an electrical signal. Detection methods include:
Electromagnetic induction: Generates eddy currents on metal objects for detection.
Capacitive sensing: Uses the electrostatic coefficient on an object's surface for detection.

Depending on the model, the detection range introduced by MEAN WELL is 1~18mm.

Ensure correct object size, detection distance, material, and installation environment (embedded or exposed installation). Refer to the specification (Rectangular Type LINK, Tubular Anti-bending Type LINK )for model selection and follow installation guidelines.

Sensitivity refers to the sensor's ability to react to target objects, which can usually be adjusted to fit different applications.

Inductive proximity sensors are specifically designed to detect objects containing metal.

Typically, inductive sensors only detect metal. For non-metallic objects, consider capacitive, optical, ultrasonic, or fiber-optic sensors for detection.

Use high-frequency sensors with a fast response rate.

Yes, but proper selection based on the specification is required.
Rectangular Type:
Tubular Anti-bending Type:

Unlike contact-based sensors, proximity sensors have high resistance to temperature, humidity, and dust.
Refer to the specification for detailed environmental tolerances.
Rectangular Type:
Tubular Anti-bending Type:

Sensors provide either digital (switching signals) or analog (voltage/current) signals, with most using digital outputs (NPN / PNP).

By using directional design and background suppression functions.

Inductive sensors detect metal objects (e.g., steel, aluminum, brass, copper).Capacitive or optical sensors can differentiate between metals, resins, liquids, powders, etc. (Note: Inductive sensors have varying detection ranges depending on metal composition.)

The number of detection outputs per second when a standard target repeatedly approaches the sensor.

Yes, but in environments with high vibration or impact, the detection distance should be selected with a safety margin.
Follow installation torque guidelines to prevent loosening due to vibration.

The operating temperature is around -20℃ to + 60℃

Capacitive sensors can detect the presence of liquids.

Some models support remote monitoring via IO-Link or other communication protocols.

It is used for power distribution and electrical connections in various devices and machinery.

Yes, depending on the model, it can connect single-core or multi-core cables.

Yes, it can connect both input and output wiring.

Yes, most terminal blocks come with label slots for easy identification.

Screw-type, clamp-type, and plug-in type connections.

Yes, some models allow parallel connections via bridging bars.

Grounding-type terminal blocks can be used if required.

Yes, but high-voltage-rated terminal blocks must be selected.

A switch controls circuit connections, enabling the start or stop of a device.

Typically 100,000 to 1,000,000 operations, depending on the model.

Except for limit switches, all switches feature waterproof designs.

Yes, please refer to the product "Pilot Light"
Its light signal can display the operating status of the switch.

It depends on the circuit design, but DPST (Double Pole Single Throw) switches can support this function.

They are widely used in automation production, semiconductor industry, automotive industry, warehousing and logistics, food industry, packaging industry, medical equipment, and home appliances, mainly in automated production industries.

Yes, all models are IP67.

Yes, they are used for positioning, detecting gripping, and placement actions, enabling material feeding and receiving.

Used for car door position detection, distance sensing, and automatic parking assistance.

Yes, especially for non-contact applications, such as liquid detection and equipment positioning.

Yes, they are commonly used for tool position monitoring and workpiece inspection.

Capacitive and optical sensors can detect thin films.

They are used for goods positioning and automatic sorting systems.

Yes, capacitive sensors are particularly suitable.

They are commonly used to detect tool positions and workpiece clamping status.

Distribution boxes, control cabinets, machinery, and electrical maintenance.

Yes, with a maximum operating temperature of 105°C.

Yes, especially for internal equipment use.

They connect external cables to DIN rail terminal blocks for circuit distribution.

DIN rail terminal blocks are suitable for such applications.

Yes, they are used for circuit distribution and signal connections.

Yes, but vibration-resistant models should be selected.

Yes, but ensure the voltage and current ratings match the application.

Yes, especially plug-in type terminal blocks.

Waterproof and dustproof switches with UV-resistant materials are best for outdoor use.

Yes.

Yes, but high-capacity and durable models should be selected.

No, they are only suitable for general household applications.

Yes.

They can be directly used for motor control.

Inductive, capacitive, optical, and ultrasonic sensors.

Select based on detection distance, target material, and environmental conditions.

All models support 4 in 1 output (NPN NO/NC, PNP NP/NC)

The response time is 300~600Hz.

Typically low-power design, suitable for long-term stable operation.

Yes, most sensors support standard protocols and have high compatibility.

Yes, the sensors have full EMI protection and they are suitable for environments with high electromagnetic interference.

The voltage range is DC 10-30V.

Plastic, metal (copper, iron, aluminum, etc.), or alloy.

DIN standard, UL certification, etc.

Typically -40°C to 105°C.

Yes, the multi-layer terminal blocks help free up more space.

DIN rail terminal blocks do not have specific protection ratings since they are installed inside equipment.

Yes, modular terminal blocks are available for flexible installation.

Typically from 1.5 mm² to 16 mm².

Yes, all terminal blocks comply with DIN rail standards.

Plastic, copper, iron, stainless steel, aluminum, silver.

Varies by model; please refer to the industrial switch in the index of product catalog (LINK), click on the part no. and you will find the related information.

Varies by model; please refer to the industrial switch in the index of product catalog (LINK), click on the part no. and you will find the related information.

No, each switch light only supports a single color.

Yes, some switches pass vibration tests, with spring-loaded clip wiring being more effective.

Panel-mounted, embedded, or DIN rail-mounted.

Electromagnetic interference, poor wiring, or unsuitable environmental conditions.

Contact the distributor or sales representative for details.

Accessories need to be purchased separately.

Contact the distributor or sales representative for sample testing.
